The extracellular matrix (ECM) is a network of molecules that provides structural support for cells and facilitates intercellular communication. It performs several functions including anchoring and separating tissues through the basement membrane, and surrounding and supporting cells via the interstitial matrix. The interstitial matrix is primarily composed of collagen, but also includes elastin and fibronectin.

Cell migration through the ECM involves three key processes. First, integrins—transmembrane proteins—mediate cell-matrix adhesion by linking the ECM to the cytoskeleton. Second, the cytoskeleton undergoes structural rearrangement, forming invadopodia, which are cellular protrusions into the surrounding matrix. Finally, matrix metalloproteases (MMPs) accumulate in invadopodia and degrade the ECM, facilitating cell invasion.

While cells in tissues exist within a 3D ECM network, traditional 2D culture systems use rigid plastic surfaces. Three-dimensional matrices better simulate the biological environment by presenting reduced stiffness compared to plastic, adding a third dimension for migration, and creating physical hindrance from the mesh of long polymers. These factors present different challenges that more accurately reflect how cells migrate in vivo.

Endothelial cells are first cultured, then treated with proteases such as trypsin and passed through a mesh filter to create a single cell suspension and break up clumps. The 3D matrix—typically composed of collagen, fibrin, laminin, or combinations thereof—is thawed on ice to prevent premature polymerization. The cell suspension is mixed with the thawed matrix and placed in an incubator where higher temperature causes the matrix to polymerize.

Time-lapse microscopy software tracks individual cells through the matrix to observe migration patterns. Cell positions are analyzed to calculate movement direction and distance in microns, which are plotted to determine locomotory activity—the average migration rate. Tube network formation is visualized and analyzed using software to identify structural features such as nodes, tubes, and loops.

Using concentric gel systems with varying matrix concentrations, researchers observed that greater stiffness in higher concentration gels resulted in increased cell displacement and overall migration distance. This demonstrates that ECM mechanical properties directly influence how cells migrate through the matrix, with stiffer environments promoting greater cell movement and invasion.

Fibrin gels, valued for their biodegradable nature, are implanted into mouse lungs and held in place with fibrinogen protein glue. Over 7 to 30 days, cell migration and blood vessel formation occur within the implanted gels. After harvesting and sectioning the lungs, imaging reveals blood vessel and alveoli formation, providing insights into angiogenesis in its in vivo organ-specific context.
