Chromogenic In Situ Hybridization as a Tool for HPV-Related Head and Neck Cancer Diagnosis

Summary

Human papillomavirus (HPV) RNA chromogenic in situ hybridization is considered to be one of the gold standards for active human papillomavirus infection detection within tumors. It allows the visualization of HPV E6-E7 mRNA expression with localization and semiquantitative evaluation of its signal.

Abstract

Human papillomavirus (HPV) infection is a major risk factor for a subtype of oropharyngeal squamous cell carcinoma (OPSCC), which tends to be associated with a better outcome than alcohol- and tobacco-related OPSCC. Chromogenic in situ hybridization (CISH) of HPV viral RNA could allow the semiquantitative evaluation of viral transcripts of the oncogenic proteins E6 and E7 and an in situ visualization with a good spatial resolution. This technique allows the diagnosis of an active infection with the visualization of HPV transcription in the tumoral HPV-infected cells. An advantage of this technique is the avoidance of contamination from nonneoplastic HPV-infected cells adjacent to the tumor. Overall, its good diagnosis performances have it considered to be the gold standard for active HPV infection identification. Since E6 and E7 viral protein interaction with cell proteins pRb and p53 is mandatory for cell transformation, HPV RNA CISH is functionally relevant and acutely reflects active oncogenic HPV infection. This technique is clinically relevant as well since "low" or "high" HPV transcription levels helped the identification of two prognosis groups among HPV-related p16-positive head and neck cancer patients. Here we present the protocol for manual HPV RNA CISH performed on formalin-fixed paraffin-embedded (FFPE) slides with a kit obtained from the manufacturer. Instead of chromogenic revelation, RNA in situ hybridization may also be performed with fluorescent revelation (RNA FISH). It may also be combined with conventional immunostaining.

Introduction

HPV RNA CISH is a powerful tool for the detection of active HPV infection, which may prove crucial in benign or malignant lesions in various locations such as the oropharynx or the uterine cervix. The detection of an active HPV infection may support the diagnosis of an HPV-induced lesion and, thereby, influence its treatment and prognosis.

HPV is the most frequent sexually transmitted infection, and over 100 viral genotypes have been described¹. Schematically, low-risk genotypes such as genotypes 6 and 11 are known to induce genital warts, recurrent respiratory papillomatosis, and other benign lesions, whereas high-risk genotypes such as genotypes 16 and also 18 are responsible for most cervical cancers and anal cancers and play a role in HNSCC oncogenesis in variable proportions as accounted for by regional epidemiological data².

Several tools are available for the detection of HPV infection. As a high-risk HPV infection leads to the expression of viral oncogenic proteins E6 and E7³, the detection of E6 and E7 transcripts is widely viewed as the gold standard for active HPV infection identification⁴. HPV RNA CISH can be performed on FFPE samples that are quite easily obtained from patients suffering from various HPV-related diseases. Its performance has been evaluated in squamous intraepithelial neoplasia in the cervix, the anus, and the vagina, and in invasive squamous cell carcinoma in the cervix, the anus, and the upper aerodigestive tract⁵: it achieves a sensitivity of over 98% among HPV DNA polymerase chain reaction (PCR)-positive cases. This is slightly better than p16 immunostaining (93%) and HPV DNA in situ hybridization (DNA ISH: 97%), which are more commonly used. In another cohort of 57 patients with squamous cell carcinoma (SCC) arising from the head and neck region, the genital region, the skin, and the urinary tract, compared to HPV DNA ISH, HPV RNA CISH achieved better sensitivity (100% versus 88%) and specificity (87% versus 74%)⁶.

P16 immunostaining is an indirect marker reflecting cell cycle disruption that may be caused (but not exclusively) by HPV infection^4,7. This cost-effective test possesses good sensitivity and a negative predictive value and is recommended as a surrogate marker of high-risk HPV infection in oropharynx cancer (OPC) by the College of American Pathologists (CAP) and by the Union for International Cancer Control (UICC)⁸.

Though this paper solely focuses on the detection of HPV in HNSCC, HPV RNA CISH is clinically relevant in various other conditions that involve HPV infection. For instance, this technique may improve the accuracy of the diagnosis of low-grade squamous intraepithelial lesions of the cervix (LSIL, formerly known as cervical intraepithelial neoplasia, grade 1 [CIN1]) for morphologically ambiguous cases⁹. Regarding oropharyngeal SCC, HPV RNA CISH allows the identification of HPV-related SCC, labeled as distinct from HPV-unrelated oropharyngeal SCC in the recent eighth edition of the TNM Classification of Head and Neck Cancer (of the Union for International Cancer Control [UICC])¹⁰. Since HPV-related SCC exhibits a better prognosis with longer survival and enhanced radiotherapy and chemotherapy sensitivity than HPV-unrelated SCC^11,12,13, the detection of HPV infection may impact patient management^14,15. Besides, HPV RNA CISH can be used for the diagnosis of HPV-related multiphenotypic sinonasal carcinoma with a higher signal than HPV DNA CISH¹⁶. Several multivariate analyses suggest that the detection of E6 and E7 transcripts is correlated with a better prognosis in oropharyngeal SCC overall^7,15,17,18 and in the subgroup of p16-positive oropharyngeal SCC^19,20.

Here we present the protocol for manual HPV RNA CISH performed on FFPE slides with a kit obtained from the manufacturer.

Protocol

The protocol follows ethical guidelines and was approved by the Ethical Committee (Comité-de-Protection-des-Personnes Ile-de-France-II, #2015-09-04).

1. Preparation of the materials

1. Preparation of 1x wash buffer
   1. Prepare 3 L of 1x wash buffer by adding 2.94 L of distilled water and one bottle (60 mL) of wash buffer (50x) (see the Table of Materials) to a large carboy. Mix well.
      NOTE: The 1x wash buffer may be prepared ahead of time and stored at room temperature for up to 1 month.
2. Preparation of counterstaining reagents
   1. Prepare 50% hematoxylin.
      1. In a fume hood, add 100 mL of Gill’s hematoxylin I (see the Table of Materials) to 100 mL of distilled water in a staining dish.
         NOTE: The 50% hematoxylin staining solution can be reused for up to 1 week.
   2. Prepare 0.02% (w/v) ammonia water (bluing reagent).
   3. In the fume hood, add 1.43 mL of 1 N ammonium hydroxide to 250 mL of distilled water in a graduated cylinder or another container. Seal the cylinder with paraffin film. Mix its contents well for 3x–5x.
      NOTE: For assay quantitation, it is critical to use ammonium hydroxide. The reagents may be prepared ahead of time. Ensure all containers remain covered.
3. Preparation of 1x target retrieval reagent
   1. In a large beaker, add 70 mL of 10x target retrieval reagent (see the Table of Materials) to 630 mL of distilled water.
   2. Place the beaker on a heating plate with a magnetic stirrer. Cover it with aluminum foil.
   3. Boil its contents at 100 °C for 10–15 min.
      NOTE: Do not let it boil for more than 30 min.
4. Reagent equilibration
   1. Ensure the hybridization oven is on and at 40 °C. Place wet humidifying paper at the bottom of the tray.
      NOTE: A hybridization oven (see the Table of Materials) is needed for steps 3.4 to 4.2.
   2. Remove the amplification reagents (AMP1–AMP6, see the Table of Materials) from the refrigerator and keep them at room temperature, at least 30 min before the relevant incubation step.
   3. Before each use, warm the target and/or control probes for at least 10 min at 40 °C in the oven or in a water bath or incubator.

2. Adhesion enhancing and deparaffinization in the fume hood

NOTE: Start the protocol with 3–5 µm-thick histological samples mounted on unstained slides.

1. In order to enhance adhesion, bake the slides at 60 °C for 1 h or at 40 °C overnight in an oven.
2. Charge the slide rack with unstained histological slides. Immerse the slide rack for 5 min in fresh xylene contained in a staining dish, with occasional agitation. repeat with fresh xylene.
3. Immerse the slide rack for 3 min in fresh 100% ethanol contained in a staining dish, with constant agitation. Repeat with fresh 100% ethanol.
4. Let the slides dry for 2 min at room temperature.
   NOTE: Do not reuse deparaffinization reagents for dehydration of the slides after the assay.

3. Tissue pretreatment

NOTE: These steps follow the “standard” pretreatment recommendation according to the manufacturer’s instructions for head and neck samples. The timing of sections 3.1 and 3.2 may need to be adjusted depending on the manipulated tissue.

1. Blockade of peroxidase activity
   1. Add 4–6 drops of hydrogen peroxide (see the Table of Materials) to each slide and incubate them for 10 min at room temperature.
   2. Wash the slides 2x for 2 min in distilled water at room temperature.
2. Breakage of RNA/tissue bounds
   1. With a claw, remove the aluminum foil from the boiling 1x target retrieval reagent (TTR1x) from section 1.3 and stop stirring. Immerse the slide rack slowly and very carefully for 15 min. Cover the beaker again with the aluminum foil.
      NOTE: Simmering has to persist during this step.
      CAUTION: Use the claw to manipulate the aluminum foil and the slide rack so as to avoid burn injuries. Make sure to wear proper personal protective equipment, such as gloves and a lab coat.
   2. With the claw, immediately transfer the hot slide rack to a distilled water bath and wash it for 2 min.
      NOTE: Make sure the samples do not cool down in the TTR1x.
   3. Wash the slides in fresh 100% ethanol for 2 min.
   4. Let the slides dry at room temperature for 2 min.
3. Barrier creation
   1. With a hydrophobic barrier pen (see the Table of Materials), draw a barrier around the sample. Let it dry out at for least 5 min.
      NOTE: Allow the barrier to really dry out. If it wears out during the procedure, do not hesitate to draw it again. Avoid touching the tissue with the pen. The protocol can be paused overnight here.
4. Protease digestion
   1. Place the slides on the slide rack and add ~4 drops of Protease Plus per sample (see the Table of Materials).
   2. Cover the humidity control tray with a lid and insert it into the hybridization oven for 30 min at 40 °C.
      NOTE: To prevent evaporation, make sure the turn knob is completely turned to the lock position.
   3. Remove the tray from the oven and remove the slide rack.
   4. One slide at a time, quickly remove any excess liquid and place the slide in a slide rack submerged in a staining dish filled with distilled water.
   5. Wash the slides 2x for 2 min in distilled water at room temperature. Agitate constantly.

4. Running the assay

NOTE: Do not let sections dry out between the incubation steps.

1. Hybridization of the HPV probe
   NOTE: Ensure the probes are prewarmed to dissolve any precipitation prior to use. For this step, instead of HPV probe, peptidyl-prolyl isomerase B (PPIB) for positive control or dihydrodipicolinate reductase (DAPB) for negative control (see the Table of Materials) may also be used.
   1. Tap and/or flick the slides to remove any excess liquid and place them in the slide rack. Add ~4 drops of HPV probe to entirely cover each section.
   2. Cover the tray with a lid and insert it into the oven for 2 h at 40 °C.
      NOTE: To prevent evaporation, make sure the turn nob is completely turned to the lock position.
   3. Remove the tray from the oven and remove the slide rack.
   4. One slide at a time, quickly remove any excess liquid and place the slide in a slide rack submerged in a staining dish filled with 1x wash buffer.
   5. Wash the slides in 1x wash buffer for 2 min at room temperature with constant agitation. Repeat this with fresh 1x wash buffer.
2. Hybridization of AMP1, AMP2, AMP3, and AMP4
   NOTE: These steps include hybridization in the hybridization oven and AMP1–AMP4 from the purchased kit (see the Table of Materials).
   1. Tap and/or flick to remove any excess liquid from the slides and place them in the slide rack. Add ~4 drops of AMP1 to entirely cover each section.
   2. Cover the tray with a lid and insert it into the oven for 30 min at 40 °C.
   3. Remove the tray from the oven and remove the slide rack.
   4. One slide at a time, quickly remove any excess liquid and place the slide in a slide rack submerged in a staining dish filled with 1x wash buffer.
   5. Wash the slides in 1x wash buffer for 2 min at room temperature with constant agitation. Repeat this with fresh 1x wash buffer.
   6. Repeat steps 4.2.1–4.2.5, but use ~4 drops of AMP2 instead of AMP1 and incubate for 15 min at 40 °C. Wash the slides 2x for 2 min, both times in fresh wash buffer.
   7. Repeat steps 4.2.1–4.2.5, but use ~4 drops of AMP3 instead of AMP1 and incubate for 30 min at 40 °C. Wash the slides 2x for 2 min, both times in fresh wash buffer.
   8. Repeat steps 4.2.1–4.2.5, but use ~4 drops of AMP4 instead of AMP1 and incubate for 15 min at 40 °C. Wash the slides 2x for 2 min, both times in fresh wash buffer.
3. Hybridization of AMP5 and AMP6
   NOTE: These steps do not include hybridization in the oven but hybridization at room temperature. AMP5 and AMP6 come from the purchased kit (see the Table of Materials).
   1. Tap and/or flick the slides to remove any excess liquid and place them in the slide rack. Add ~4 drops of AMP5 to entirely cover each section.
   2. Cover the tray with a lid and incubate for 30 min at room temperature.
   3. One slide at a time, quickly remove any excess liquid and place it in a slide rack submerged in a staining dish filled with 1x wash buffer.
   4. Wash the slides in 1x wash buffer for 2 min at room temperature with constant agitation. Repeat this with fresh 1x wash buffer.
   5. Repeat steps 4.3.1–4.3.4, but use ~4 drops of AMP6 instead of AMP5 and incubate for 15 min at room temperature. Wash the slides 2x for 2 min, both times in fresh wash buffer.

5. Signal detection with 3,3'-diaminobenzidine

CAUTION: Diaminobenzidine (DAB) is toxic. Follow appropriate precautions and safety guidelines when disposing of and handling this chemical.

1. Mix equal volumes of DAB-A and DAB-B (see the Table of Materials) in an appropriately sized tube by dispensing the same number of drops of each solution. Make ~120 µL of DAB substrate per section (~2 drops of each reagent/total of 4). Mix it well for 3x–5x.
2. Take each slide, one at a time, from the slide rack and tap and/or flick to remove the excess liquid before placing it in the slide rack.
3. Pipette ~120 μL of DAB onto each tissue section. Ensure the sections are covered, and incubate for 10 min at room temperature.
4. Dispose the remaining DAB according to local regulation and insert the slide into a slide rack submerged in a staining dish filled with tap water.

6. Counterstaining

1. Move the slide rack to a staining dish containing 50% hematoxylin staining solution let it rest for 30 s at room temperature. Note that the slides will become purple.
2. Immediately transfer the slide rack back to a staining dish containing tap water, and wash the slides 3x–5x by moving the rack up and down.
3. Keep repeating the washing step with fresh tap water until the slides are clear, while sections remain purple.
4. Replace the tap water in the staining dish with 0.02% ammonia water. Move the rack up and down 2x–3x. Note that the tissue section should turn blue.
5. Replace the ammonia water with tap water. Wash the slides 3x–5x.

7. Dehydration

1. Move the slide rack to a staining dish containing 70% ethanol in the fume hood and let it rest for 2 min with occasional agitation.
2. Move the slide rack to a first staining dish containing 100% ethanol and let it rest for 2 min with occasional agitation.
3. Move the slide rack to a second staining dish containing 100% ethanol and let it rest for 2 min with occasional agitation.
4. Move the slide rack to a staining dish containing xylene and let it rest for 5 min with occasional agitation.

8. Slide mounting

1. Remove the slides from the slide rack and lay them flat with the sections facing up in the fume hood.
2. Mount one slide at a time by adding 1 drop of a xylene-based mounting medium to each slide and carefully placing a 24 mm x 50 mm coverslip over the section. Avoid trapping any air bubbles.
3. Air-dry the slides for ≥5 min.

9. Sample evaluation

1. Examine the tissue sections under a standard brightfield microscope at 20x–40x magnification.

Results

As described here, in head and neck squamous cell cancer, a case may be considered positive in the presence of brown punctiform staining in the cytoplasm or in the nuclei of tumor cells. In most studies, the signal is considered as either “positive” or “not detected”¹⁴. Methods of semiquantification of the signal have been reported but lack standardization between teams. For example, in some studies, the signals were scored as 1+ with 1–3 dots per tumor cell, 2+ with 4–9 dots per tumor cell, or 3+...

Discussion

HPV RNA CISH performed with a purchased kit is a powerful tool for the detection of viral transcripts and it indicates active HPV infection. Performed manually, the steps of the protocol are overall easy to follow, and the purchased kit is convenient. This technique allows the staining of 19 histological samples plus one control slide at once, and the assay lasts around 8 h. It is critical not to let the samples dry out between steps unless otherwise mentioned. The pretreatment condition may need to be adjusted depending...

Materials

List of materials used in this article

Name	Company	Catalog Number	Comments
Hematoxylin solution, Gill No. 1	Merck	GHS132
HybEZ Oven (110v)	Advanced Cell Diagnostics Inc.	321710
HybEZ slide rack	Advanced Cell Diagnostics Inc.	300104
ImmEdge Hydrophobic Barrier Pen	Advanced Cell Diagnostics Inc.	310018
RNAscope 2.5 HD Detection Reagents-BROWN	Advanced Cell Diagnostics Inc.	322310	This kit includes amplification reagents AMP1, AMP2, AMP3, AMP4, AMP5 and AMP6, and detection reagents DAB-A and DAB-B
RNAscope 3-Plex Negative Control Probe	Advanced Cell Diagnostics Inc.	320871	DAPB
RNAscope 3-Plex Positive Control Probe	Advanced Cell Diagnostics Inc.	320861	PPIB
RNAscope H202 & Protease Plus Reagent	Advanced Cell Diagnostics Inc.	322330	Hydrogen Peroxyde x2 and Protease Plus x 1
RNAscope Probe- HPV16/18	Advanced Cell Diagnostics Inc.	311121
RNAscope Target Retrieval Reagents	Advanced Cell Diagnostics Inc.	322000
RNAscope Wash Buffer Reagents	Advanced Cell Diagnostics Inc.	310091	Wash Buffer 50X x4
