A Protocol for Explant Cultures of IDH1-mutant Diffuse Low-grade Gliomas

Summary

IDH1-mutant diffuse low-grade gliomas are rare tumors that are difficult to culture. We introduce a simple, non-enzymatic explant method that preserves IDH1-mutant protein expression and sustains cultures for months. Importantly, this technique works with cryopreserved tumors, offering a valuable resource for glioma research.

Abstract

Diffuse gliomas, the most prevalent primary brain tumors, are categorized into low and high grades based on histopathological criteria and genetic mutations. Diffuse low-grade gliomas constitute a subset, predominantly afflicting young adults and predisposing to high-grade gliomas. There are two main types of diffuse low-grade gliomas: astrocytomas and oligodendrogliomas, each defined by distinct genetic and histological features. These tumors characteristically exhibit a mutated variant of the metabolic enzyme IDH1, disrupting cellular differentiation. They are heterogeneous, comprising both proliferative stem cells and more differentiated, quiescent glial cells.

Patient-specific, in vitro tumor models hold significant potential for unraveling oncogenic mechanisms and tailoring drug selection for personalized therapy. However, the absence of reliable in vitro models specifically for IDH1-mutant low-grade gliomas has hindered fundamental and translational research. Here, we present a simple method for culturing IDH1-mutant tumors as explants in defined media without needing enzymatic dissociation. These explants can be sustained for extended periods, maintaining IDH1-mutant protein expression as well as markers for oligodendrocyte progenitor cells such as ASCL1 (MASH1), OLIG1, and OLIG2 and for astrocytes (GFAP, SOX9). They can also be established from frozen tumors in DMSO. These cultures can serve as a valuable platform for drug screening, videomicroscopy, and gene studies, thus facilitating advancements in understanding and treating these challenging tumors. They also offer the potential to derive IDH1-mutant cell lines.

Introduction

Diffuse gliomas are the most frequent primary brain tumors. These tumors are currently incurable despite very intense treatment (surgery, radio, and chemotherapy)¹. Increasing evidence supports the hypothesis that gliomagenesis originates from adult stem or glial progenitor cells resident in the brain². Although glioblastomas represent the most aggressive type, diffuse low-grade gliomas (DLGG, grade 2 tumors) are also prevalent (15% of diffuse gliomas)^1,3. DLGGs grow slowly and migrate along white matter tracts, a hallmark of this 'diffuse' neoplasm⁴. These DLGG very often recur despite treatment, ultimately progressing to high-grade malignancies (grades 3 and 4)⁵.

DLGG are characterized by a missense mutation in the isocitrate dehydrogenase 1 or 2 gene (IDH1 or IDH2), resulting in the aberrant production of the oncometabolite 2-hydroxyglutarate (2HG). This disrupts cell differentiation through epigenetic dysregulations⁶. IDH1-mutant gliomas are further classified into subtypes: astrocytomas typically have mutations in ATRX and P53, while oligodendrogliomas are characterized by 1p19q deletions⁷. These tumors exhibit a heterogeneity of tumoral cells. Single-cell RNA sequencing and immunocharacterization have revealed a diverse population of tumor cells, displaying stem-cell-like, astrocyte-like, and oligodendrocyte-like phenotypes within these tumors^8,9.

In contrast to glioblastoma, which benefits from readily available, long-term cultures and cell lines, there exists a notable scarcity of cellular tools tailored for investigating IDH1-mutant tumors¹. This presents a significant obstacle to advancing therapeutic development and deepening our understanding of IDH1-mutant gliomagenesis and disease progression. Traditional serum-grown cell lines, while long-utilized, inadequately replicate original tumors, displaying altered transcriptional profiles. Alternatively, serum-free culture conditions, whether in 2D or 3D tumoroid models, more effectively preserve the transcriptional profiles of tumor cells and their in vivo phenotypes, such as invasion into normal brain tissue^10,11.

In addition, short-term cell cultures derived from a patient's surgical specimen preserve the molecular profile and cellular diversity of the tumor, thereby better representing the biological traits of tumors compared to cell lines¹². Herein, we introduce a straightforward non-enzymatic method for culturing IDH1-mutant diffuse low-grade gliomas culture as explants derived from fresh or frozen patient resections, aiming to address the need for improved in vitro models for glioma research and therapeutic development. They also offer the potential to derive IDH1-mutant cell lines.

Protocol

The tumor fragments utilized in this protocol were obtained from a well-characterized and ethically approved collection, with patient consent. This research was conducted under the project titled Gliomacult: Characterization and Primary Cultures of Low-Grade Gliomas (Project No. RECH/P722/1-5) and was approved by the tumor biobank's scientific council on August 28, 2023.

1. Preparation of culture plates

NOTE: Perform these steps under a sterile tissue culture laminar flow hood.

1. At least 1 h before culture, prepare poly-D-lysine (PDL) and laminin-coated 24 well plates.
   1. Dilute 10 mg of PDL powder in 100 mL of borate buffer (pH 8.4) for a final concentration of 100 µg/mL. Once dissolved, filter the solution (0.22 µm) for sterility. PDL is ready to use; prepare 3 mL aliquots and store them at -20 °C.
   2. Thaw the 1-2 mg/mL laminin tube at 4 °C to avoid gel formation. Prepare 50 µL aliquots and store them at -20 °C.
      NOTE: Repeating thawing and freezing should be avoided.
   3. Plate coating
      1. Optional step: place sterile coverslips Ø, 13 mm, suitable for cell culture dishes, in a 24-well plate, one coverslip per well.
         NOTE: This step is for further immunostaining of glioma explants.
      2. For the coating of the wells, mix the 3 mL of the PDL solution in 9 mL of 1x PBS and add 50 µL of laminin. Add 500 µL of this solution to each well for a 1-2 µg/cm² coating concentration. Incubate the coated plates at room temperature, preferably with slow rocking (15 RPM), for at least 1 h.
      3. Immediately before the culture, remove the PDL-laminin solution and rinse twice with sterile 1x PBS.
         NOTE: Do not let the wells dry out.

2. Media

1. Culture IDH1-mutant explants in a defined medium comprising DMEM/F12 supplemented with L-glutamine, along with a serum-replacement blend consisting of N2 and B27 without Vitamin A. Use antibiotics, including ciprofloxacin, gentamicin, and fungin, to prevent bacterial and fungal contamination. Additionally, incorporate growth factors heparin, EGF, and FGF2 into the medium, filter it (0.2 µm), and store it for up to 2 weeks at 4 °C.
   NOTE: For details on media ingredients and preparation, refer to Table 1 and the Table of Materials.

3. Explant preparation

1. Before sample processing, prepare the workspace and sterile tools as depicted in Figure 1A. Sanitize a cool pack by spraying it with 70% ethanol. Sterilize scissors and forceps by immersing them in 70% ethanol and rinsing them with PBS.
2. Promptly transfer the tumor resection for culture on ice, ideally within 2 h post surgical extraction (Figure 1B).
   NOTE: The tumor sample should have a minimum diameter of 9-10 mm to ensure better results. The tissue is transported without culture medium as this method is preferred for histological purposes. The absence of liquid prevents ice crystal formation during flash freezing, thereby preserving tissue integrity for subsequent histological examination if necessary.
3. Place the culture dish with the tumor specimen over the cool pack and gently rinse it with 1X PBS to remove excess blood.
4. The resected tumor often exhibits significant size and heterogeneity, comprising tumor mass, infiltrated tissue, and non-tumoral components (Figure 1C). Select portions displaying a gray color with a soft or jelly-like texture for tumor cell isolation, as they tend to contain more tumor cells. Conversely, avoid hard and white regions as they may contain fewer tumor cells suitable for culture (Figure 1D), as well as blackened areas, as they are likely a result of electrocautery and may not provide reliable results for analysis.
5. Transfer the selected samples into a 1.5 mL microtube or cryovial for mincing. Add 1 mL of sterile media to the 1.5 mL microtube or cryovial and chop the sample with the sterile scissors until small pieces (1-2 mm³) are obtained.
   NOTE: Approximately 1-2 min of chopping is necessary to obtain tiny fragments, typically 1-2 mm³ in size (Figure 1E).
6. With sterile scissors, carefully trim the end of a blue 1,000 µL pipette tip to create a wide opening, roughly 3-4 mm in diameter. Employing this modified tip, pipette 50-200 µL of the minced tissue fragments and distribute them evenly across each well. Because the smaller pieces tend to settle rapidly, gently re-homogenize the suspension in each well to ensure uniform distribution.
   ​NOTE: Avoid overcrowding and maintain a balance by not introducing an excessive number of fragments into each well (Figure 1F).
7. Incubate the tumor fragments at 37°C in a 5% CO2 incubator with 100% humidity. Change the media every day if the tumor's metabolic activity (indicated by rapid yellowing of the media) and the number of fragments in each well requires it. During media changes, exercise care by delicately aspirating the media using a pipette equipped with a 200 µL tip, ensuring to avoid disturbing any adhering tumor fragments.

Figure 1: Tumor explant culture procedure. A diffuse low-grade glioma resection was obtained from a 44-year-old patient diagnosed with a grade II astrocytoma according to the WHO 2021 classification. The tumor exhibited an IDH1 mutation (Exon 4 c.395 G>A, p.Arg132His) and a TP53 mutation (Exon 8 c.843_844delinsGT, p.Asp281_Arg282delinsGluHis), along with the absence of ATRX staining. No mutations were detected in the Ets/TCF binding sites (C250T and C228T) of the TERT gene. (A) The working surface comprises a cool pack, providing an environment that minimizes sample degradation and maintains the viability of biological components. These precautions are important for preserving the quality and integrity of the tissue. (B) Transport of the sample from the hospital to the lab should be done on ice. (C) Tumor resection fragment. Arrows show the most suitable parts for culture. (D) Dissection of the tumor is performed to select the most relevant part to be minced. In our experience, white matter is generally less likely to generate successful explants. (E) Tumor fragments of approximately 1-2 mm³ of diameter in a 15 mL tube after being mechanically minced with scissors. (F) The number of tumor pieces required for the proper seeding is shown for wells on a 24-well plate. Please click here to view a larger version of this figure.

4. Minced tumor cryopreservation and thawing

NOTE: Cryopreservation ensures backup in case of contamination and loss of explant cultures or to process the tumor samples later.

1. Cryopreservation: Prepare the freezing medium (20% v/v DMSO solution) by adding 2 mL of DMSO to 8 mL of cell culture medium.
2. Combine 1 volume of the minced tumor suspension with an equal volume of the 20% DMSO freezing medium to achieve a final concentration of 10% DMSO. Carefully pipette the mixture up and down to ensure thorough blending, then dispense approximately 1 mL into cryovials.
3. Rapidly transfer the cryovials into a cryogenic container for gradual temperature reduction, followed by overnight incubation at -80 °C before final storage in liquid nitrogen.
   NOTE: This step must be performed immediately after the cells are placed in the freezing medium, as certain cryoprotectants, like DMSO, can be harmful if the cells are exposed to them at room temperature for longer than necessary.
4. Thawing: Remove the cryovials from the liquid nitrogen and immediately place them in a 37 °C water bath until around 80% of the cells have thawed.
5. To remove the DMSO, quickly pipette the suspension into a 15 mL centrifuge tube containing 5 mL of prewarmed 1x PBS and centrifuge at 300 × g for 5 min.
6. Remove the supernatant and repeat the wash with 1X PBS followed by centrifugation (step 4.5). Aspirate the supernatant, taking care not to disturb the pellet, and add the appropriate amount of medium to transfer into a precoated PDL-Laminin 24-well plate and place in the incubator.
7. After 24 h, verify that the cells have attached. After a few days, remove non-adherent fragments by replacing the culture media.

5. Passage of the culture

NOTE: Once established, explants can be used for videomicroscopy or immunostaining. Alternatively, if tumor cells have migrated out of the explant and appear healthy, the explant can be passaged through enzymatic dissociation and reseeded in wells for further experimentation. However, it is important to note that this protocol is not designed for repeated passaging. Typically, only a single passage can be attempted before the tumor cells become senescent or die. Not all explant cultures will result in successful passage.

1. To passage, remove old media, rinse with 1X PBS, and add (125 µL) 0.05% trypsin-EDTA to the wells and incubate for 3-4 min at 37 °C, followed by the addition of 6.5 µL of Trypsin Inhibitor, 12 µL of 20 mM CaCl₂ (final dilution to 2mM), and 1 µL of DNAse I.
   NOTE: The incubation time needed for dissociation may vary depending on the culture. It is important to check whether the cells are detached after at least 3 min. Typically, the explant may not be fully dissociated into a single-cell suspension, and small clusters are often retained, which can generate new explant cultures.
2. With a p1000 set on 500-600 µL, flush gently to disaggregate explants. Avoid bubble formation.
3. Add 5 mL of 1x PBS and centrifuge for 5 min at 300 × g. Aspirate the supernatant, resuspend the pellet in fresh prewarmed medium, and count for seeding.
4. Identify cultures with the potential to generate cell lines by observing dividing cells under a phase-contrast microscope. These dividing cells typically have a rounded morphology and visible chromosomes, as shown in Figure 2A.

Results

After a few days, some tumor fragments will adhere to the well surfaces, initiating the outgrowth of cells from the explants. The time between the initial plating and the appearance of tumoral growing cells is different from sample to sample. The initial cultures often contain substantial cellular debris, making it difficult to assess the presence of viable cells. Consequently, the culture should be maintained for a minimum of 4 weeks. Once the cells start to grow, elongated cells with a bipolar or multipolar appearance ...

Discussion

Developing in vitro and preclinical models for IDH1-mutant low-grade gliomas is particularly challenging due to the slow growth of these tumors and the complexity of replicating the extensive genomic and epigenomic alterations caused by the IDH mutation. Moreover, these infiltrative tumor cells actively interact with surrounding cells, including immune, endothelial, glial, and neuronal cells, potentially relying on them for survival. This complex interplay is difficult to replicate in a laboratory setting.

Materials

List of materials used in this article

Name	Company	Catalog Number	Comments
Anti-ASCL1	BD Pharmingen™	556604	Dilution 1:500
Anti-ATRX	Sigma-Aldrich	HPA001906	Dilution 1:100
Anti-CD68	Agilent	M081401-2	Dilution 1:500
Anti-GFAP	Aves Labs	AB_2313547	Dilution 1:500
Anti-IBA1	Fujifilm Wako Antibodies	019-19741	Dilituion 1:1000
Anti-IDH1 (R132H) mouse Monoclonal Antibody	Dianova	DIA-H09
Anti-Ki67	BD Pharmingen™	556003	Dilituion 1:1000
Anti-OLIG1	R&D Systems®	AF2417	Dulituion 1:300
Anti-OLIG2	Sigma-Aldrich	MABN50	Dilution 1:250
Anti-SOX9	Abcam®	EPR14335-78	Dilution 1:100
B-27 Supplement (50x), minus vitamin A	Thermo Fisher Scientific	12587010
Bovine Serum Albumin (BSA)	CiteAb	A-421-100
Ciprofloxacin HCl	Sigma-Aldrich	PHR1044-1G
CoolCell	Corning®	432000	Cell Freezing Container, for 12 x 1 mL or 2 mL Cryogenic Vials
Cover slip Ø, 13 mm	Karl Hecht™ Assistent™	328017
Dimethyl Sulfoxide (DMSO)	Sigma-Aldrich	D8418
DMEM/F-12, no glutamine	Thermo Fisher Scientific	21331020
DNAse I	Sigma-Aldrich	10104159001
Dulbecco′s Phosphate Buffered Saline (PBS) 1x	Sigma-Aldrich	D8537
Falcon 100 mm TC-treated Cell Culture Dish	Corning®	353003
Falcon 24-well Clear Flat Bottom	Corning®	353047	TC-treated Multiwell Cell Culture Plate, with Lid, Sterile
Fungin	InvivoGen	ant-fn-1
Gentamicin	Thermo Fisher Scientific	15750-037
Heparin	Sigma-Aldrich	H3149-100KU
HEPES	Sigma-Aldrich	H-3375
Human EGF	PeproTech	AF-100-15-1MG
Human FGF-basic	PeproTech	100-18B-1MG
Laminin	Sigma-Aldrich	L2020
L-Glutamine	Thermo Fisher Scientific	25030-024
N-2 Supplement (100x )	Thermo Fisher Scientific	17502-048
PDL	Sigma-Aldrich	P7886
Serum acrodisc 37 mm syringe filter with GF/0.2 µm Supor	PALL Corporation	4525
Trypsin Inhibitor	Thermo Fisher Scientific	17075-029
Trypsin-EDTA (0.05%), phenol red	Thermo Fisher Scientific	25300054
Zeiss Z1 Apotome 3 microscope	Zeiss		straight widefield epifluorescence microscope
