8.13
Flachriemen: Problembehebung
Flachriemen sind in vielen industriellen Anwendungen entscheidend, da sie dazu dienen, Kraft von einer Riemenscheibe auf eine andere zu übertragen. Da…
Ein Flachriemen wickelt sich um zwei Riemenscheiben, A und B, mit Radien von 30 cm bzw. 10 cm.
Der Winkel zwischen dem Riemen und der Horizontalen beträgt 20 Grad an den Riemenscheiben.
Riemenscheibe B dreht sich im Uhrzeigersinn und treibt Riemenscheibe A an, wodurch die Spannung T2 an einem Ende des Riemens und die Spannung T1 am anderen Ende des Riemens entsteht.
Wenn man davon ausgeht, dass die maximal zulässige Spannung T2 1000 N und der Haftreibungskoeffizient zwischen dem Riemen und den Riemenscheiben 0,4 beträgt, was ist das maximale Moment auf der Riemenscheibe A?
Der aus der Geometrie des Systems berechnete Kontaktwinkel zwischen Band und Oberfläche beträgt 140 Grad.
Der Kontaktwinkel zwischen Riemen und Oberfläche im Bogenmaß und der Haftreibungskoeffizient werden in den Ausdruck für die Riemenspannungen eingesetzt, um T1 zu erhalten.
Wenn sich die Riemenscheibe B im Uhrzeigersinn dreht, erzeugt eine an der Riemenscheibe B erzeugte Spannungsdifferenz ein Moment an der Riemenscheibe A.
Es wird ein Freikörperdiagramm für die Riemenscheibe A gezeichnet und die Momentengleichgewichtsbedingung angewendet.
Die Radius- und Spannungswerte werden ersetzt, um das maximale Moment zu erhalten.
View the full transcript and gain access to JoVE Core videos
Q1: How does the belt-to-surface contact angle affect tension calculations in a flat belt system?
The belt-to-surface contact angle, measured in radians, is a critical input for determining belt tensions using the friction relationship. In this problem, the contact angle is 140 degrees, calculated from the system's geometry where the belt wraps around pulleys with different radii. This angle, combined with the coefficient of static friction of 0.4, is substituted into the tension expression to find T1 from the maximum allowable T2 of 1000 N.
Q2: What is the relationship between tension difference and moment generation in pulley systems?
When pulley B rotates clockwise, it creates a tension difference between the two ends of the belt—T2 minus T1. This tension difference acts at different radii on pulley A, generating a moment. The moment is calculated by multiplying the tension difference by the radius of pulley A, which is 30 cm. This moment represents the power transmission capability of the belt system.
Q3: How do you apply moment equilibrium to find the maximum moment on a pulley?
A free-body diagram of pulley A is drawn showing both tension forces acting at the pulley's radius. Moment equilibrium requires that the net moment equals zero at static conditions. By substituting the calculated tension values and the pulley radius into the moment equation, the maximum moment is determined. In this case, the maximum moment on pulley A is 186.921 N·m.
Q4: Why is the coefficient of static friction important in belt tension analysis?
The coefficient of static friction of 0.4 determines how much tension can be transmitted between the belt and pulley surfaces without slipping. This value is substituted into the belt tension relationship along with the contact angle to calculate T1 from the maximum allowable T2. A higher friction coefficient would allow greater tension transmission, while a lower coefficient would reduce it.
Q5: What role does pulley radius play in calculating the maximum moment?
Pulley radius directly determines the moment arm for the tension forces. Pulley A has a radius of 30 cm, while pulley B has 10 cm. The larger radius of pulley A means that the same tension difference produces a greater moment. The maximum moment is calculated by multiplying the tension difference by pulley A's radius of 0.3 m.
Q6: How does the geometry of the belt system determine the contact angle?
The belt-to-surface contact angle is calculated from the system's geometry, including the radii of both pulleys and the angle between the belt and horizontal at the pulleys. In this problem, with pulley radii of 30 cm and 10 cm and a 20-degree angle to the horizontal, the resulting contact angle is 140 degrees. This geometric relationship is essential for accurate tension calculations.
Q7: What is the calculated tension T1 when T2 reaches its maximum allowable value?
When the maximum allowable tension T2 is 1000 N, the calculated value of T1 is 376.93 N. This T1 value is determined by substituting the belt-to-surface contact angle in radians and the coefficient of static friction of 0.4 into the friction-based tension relationship. The tension difference of 623.07 N between T2 and T1 then generates the maximum moment on pulley A.
