Name: Measurement of Compressive Stress-Strain Response at Small-Strains (Video) | JoVE Journal
Uploaded: 2025-12-05T14:40:00.000+00:00
Duration: 2 min 58 s
Description: Learn a low-cost compression test method for measuring mechanical properties in the small-strain region using polymer-based materials. This protocol enables accurate force-displacement measurement with reliable calibration.
